| Copier Type |
Monochrome Laser Multifunctional |
| Functions |
Print, Copy, Scan, Send, Store and Optional Fax |
| Speed |
Print/Copy: 45 ppm (A4) 22 ppm (A3) |
| Resolution |
Print: Up to 1,200 dpi x 1,200 dpi, Copy: 1,200 dpix1,200 dpi, Scan: 600 x 600 dpi, Fax: 400 x 400 dpi, 200 x 400 dpi |
| Processor |
Canon Dual Custom Processor (Shared) |
| Memory |
Standard : 3.0GB RAM, Fax: Up to 30,000 pages |
| Hard Disk Drive |
Standard: 250GB, Maximum: 1TB, Mirroring Hard Disk Drive: Optional 250GB, 1TB |
| Warm-Up Time |
24 Seconds or Less |
| Recovery from Sleep Mode |
10 Seconds or Less |
| First Page Out Time |
Approx. 3.8 seconds or less |
| Duplex Print |
Automatic (Standard) |
| Feeding Capacity |
Standard : 1,180 Sheets, Maximum : 6,330 Sheets, Output Capacity: Paper Output Capacity (80gsm/A4), Standard : 250 Sheets, Maximum : 3,350 Sheets (with STAPLE FINISHER-Y1/BOOKLET FINISHER-Y1) |
| Media Type |
Cassettes (1/2) : Thin paper, Plain paper, Thick paper, Colour paper, Recycled paper, Pre-punched paper, Multi-Purpose Tray: Thin paper, Plain paper, Thick paper, Colour paper, Recycled paper, Pre-punched paper, *Transparency, Tracing paper, Label, Bond p |
| Media Size |
Supported Media Sizes: Cassette 1 : Standard size : B4, A4, A4R, B5, B5R, A5R, Custom Size : Min. 139.7 x 182 mm up to 297 x 390 mm, Cassette 2: Standard size : A3, B4, A4, A4R, B5, B5R, A5R, Foolscap, India Legal, F4A, Custom Size : Min. 139.7 x 182 mm u |
| Media Weight |
Cassette Feeding Unit-AN1: 60 to 128 gsm, High Capacity Cassette Feeding UNIT-B1: 60 to 128 gsm, Paper Deck Unit-F1:60 to 128 gsm |
| Multiple Copies / Prints |
Up to 999 copies |
| Zoom Rate |
Magnifiation: 25% - 400% (1% Increments), Preset Reductions: 25%, 50%, 61%, 70%, 81%, 86%, Preset Enlargements: 115%, 122%, 141%, 200%, 400% |
| Scanner Type |
Type: Single-pass Duplexing Automatic Document Feeder or Duplexing Automatic Document Feeder, Single-sided scanning: 38 to 128 gsm (BW), 64 to 128 gsm (CL), Double-sided scanning: 50 to 128 gsm (BW), 64 to 128 gsm (CL) |
| Fax Features |
Optional on all models, Max number of connection: 4 |
| Modem Speed |
Super G3 : 33.6 kbps, G3 : 14.4 kbps |
| Speed Dial |
Max. 200, Group Dials: Max. 199 dials |
| Address Book Capacity |
LDAP (2,000)/Local (1,600)/One-touch (200) |
| Network Interface |
Network Standard : 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n), Optional : NFC, Bluetooth |
| Control Panel |
Standard : 10.1 inch TFT LCD WSVGA Colour Touch Panel |
| OS Compatibility |
Windows Vista/Server 2008/Windows 7/Server 2008, R2/ Windows 8/Server 2012/Windows 8.1/Server 2012 R2/ Windows 10, MAC OS X (10.6.8 or later) |
| Security |
Nework: IP/Mac Address Filtering, IPSEC, TLS Encrypted Communication, SNMP V3.0, IEEE 802.1X, IPv6, SMTP Authentication, POP Authentication before SMTP |
| Power |
220-240V(±10 %),50/60 Hz (±2 Hz) 5.2A |
| Environment |
Temperature: 10 to 30 ºC, Humidity: 20 to 80 % RH (no condensation) |
| Power Consumption |
Maximum: 1.5 kW, Standby: Approx. 37 W*, Sleep mode: Approx. 0.9 W ** |
| Interface |
Standard : USB 2.0 x2 (Host), USB 3.0 x1 (Host), USB 2.0 x1 (Device), Optional : Serial Interface, Copy Control Interface |
| Dimension |
With SINGLE PASS DADF-A1: 587 x 740 x 945 mm, With DADF-AV1: 587 x 750 x 926 mm |
| Weight |
Approx. 86.6kg (with SINGLE PASS DADF-A1), Approx. 81.3kg (with DADF-AV1) |
