| Copier Type |
Monochrome Laser Multifunctional |
| Functions |
Print, Copy, Scan, Send, Store and Optional Fax |
| Speed |
Print/Copy: 32 ppm (A3), 55 ppm (A4) |
| Resolution |
Print: 1,200 dpi x 1,200 dpi, 600 dpi x 600 dpi, Copy: Reading:600 dpi x 600 dpi, Printing: 1,200 dpi x 1,200 dpi, Scan: 600 x 600 dpi, Fax: 400 x 400 dpi, 200 x 400 dpi |
| Memory |
Standard : 3.0GB RAM, Fax: Up to 6,000 pages |
| Hard Disk Drive |
Standard: 250GB, Maximum: 1TB, Mirroring Hard Disk Drive: Optional 250GB, 1TB |
| Warm-Up Time |
30 Seconds or Less |
| Recovery from Sleep Mode |
30 Seconds or Less |
| First Page Out Time |
Approx. 3.3 seconds or less |
| Duplex Print |
Automatic (Standard) |
| Feeding Capacity |
Paper Input (Standard): 1,500 sheets x 2 paper drawers+ 550 sheets cassettes x 2 cassettes (80gsm) 100 sheets Multi-purpose tray(80gsm), Paper Input (Option)POD DECK LITE-C1: 3,500 sheets (80gsm), PAPER DECK UNIT-E1: 3,500 sheets (80gsm), Maximum Paper In |
| Media Type |
Upper Left/Right Cassettes(1/2):Thin paper, Plain paper, Recycled paper, Colour paper,Heavy paper, Pre-punched paper, Letterhead, Bond paper, Lower Cassettes (3/4): Thin paper, Plain paper, Recycled paper, Colour paper,Heavy paper, Pre-punched paper, Lett |
| Media Size |
Supported media sizes: Upper Left/Right Drawers (1/2): Standard size: A4, Lower Cassettes (3/4): Standard size: A3, A4, A4R, A5R, Custom size: 139.7 mm x 182 mm to 297 mm x 431.8 mm, Multi-purpose Tray: Standard size: A3, A4, A4R, A5R, Custom Size : 100 m |
| Media Weight |
Cassettes:52 to 220 gsm, Multi-purpose tray: 52 to 256 gsm, Duplex:52 to 220 gsm |
| Multiple Copies / Prints |
Up to 9,999 copies |
| Zoom Rate |
Magnifiation 25% - 400% (1% Increments), Preset Reductions 25%, 50%, 64%, 73%, 78%, Preset Enlargements 121%, 129%, 200%, 400% |
| Scanner Type |
Type: Colour fltbed plus Single-pass duplex automatic document feeder (1-Pass Duplex Scan), Media Size: A3, A4, A4R, A5, A5R, Capacity: 300 Sheets (80 gsm), Double Sided Printing: 2-sided to 2-sided (Automatic) |
| Output File Format |
Standard: JPEG, TIFF , PDF/XPS (Compact), PDF (PDF/A-1b, Optimize for Web, Apply Policy) Optional: PDF(Trace&Smooth, Encrypted), PDF/XPS (Digital Signature), PDF/XPS(Searchable), Offie Open XML(PowerPoint, Word) |
| Fax Features |
Optional on all models, Max number of connection: 4 |
| Modem Speed |
Super G3: 33.6 kbps, G3: 14.4 kbps |
| Speed Dial |
Max. 200, Group Dials: Max. 199 dials |
| Address Book Capacity |
LDAP (2,000)/Local (1,600)/Speed dial (200) |
| Network Interface |
Standard: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n), Others: Standard: USB 2.0 x2 (Host), USB 3.0 x1 (Host), USB 2.0 x1 (Device) Optional: Serial Interface,Copy Control Interface |
| Control Panel |
10.1 inch TFT LCD WSVGA Colour Touchpanel, Optional 10.4 inch TFT LCD SVGA Colour Touchpanel |
| Compatible Accessories |
Toner Cartridge/s NPG-54 TONER BK, Toner (Estimated Yield @6% Coverage) 56,000 pages |
| OS Compatibility |
Server 2003/Server 2003 R2Vista/Server 2008/Windows 7/Server 2008 R2/Windows 8/Server 2012/Windows 8.1/Server 2012 R2/Windows 10, MAC OS X (10.5.8 or later) |
| Security |
IP/Mac Address Filtering, IPSEC, TLS Encrypted, Communication, SNMP V3.0, IEEE 802.1X, IPv4/IPv6, SMTP Authentication, POP Authentication before SMTP, Secure Print. |
| Power |
220-240V(±10 %) , 50/60Hz (±2 Hz) , 10Amp |
| Environment |
Temperature: 10 to 30 ºC (50 to 86 ºF), Humidity: 20 to 80 % RH (no condensation) |
| Power Consumption |
Maximum: Approx. 2.4 kW, Standby: Approx. 260 Wh, Energy Saver Mode: Approx. 260 Wh, Sleep mode: Approx. 0.9 W or less*5, Typical Electricity: 4.9 kWh (iR-ADV 6555i) Consumption (TEC) rating2: 6.1 kWh (iR-ADV 6565i), 6.7 kWh (iR-ADV 6575i) |
| Interface |
Standard : USB 2.0 x2 (Host), USB 3.0 x1 (Host), USB 2.0 x1 (Device), Optional : Serial Interface, Copy Control Interface |
| Dimension |
670 mm x 779 mm x 1,220 mm |
| Weight |
Approx. 234kg |
