| Product Type |
Industrial Printer |
| Print Method |
Thermal transfer and direct thermal printing |
| Body Material |
Metal frame and bi-fold metal media cover |
| Sensors |
Dual media sensors: transmissive and reflective |
| Memory |
256 MB SDRAM memory, 512 MB on-board linear Flash memory |
| Resolution |
203 dpi/8 dots per mm, 300 dpi/12 dots per mm (optional), 600 dpi/24 dots per mm (optional for ZT410 only) |
| Print Speed |
14 ips/356 mm per second |
| Print Width |
1.00"/25.4 mm to 4.5"/114 mm tear/cutter, 1.00"/25.4 mm to 4.25"/108 mm peel/rewind |
| Media Type |
Continuous, die-cut, notch, black-mark |
| Media Size |
8.0"/203 mm O.D. on a 3"/76 mm I.D. core |
| Media Thickness |
0.0023"/0.058 mm to 0.010"/0.25 mm |
| Ribbon Features |
Standard Length : 1476'/450 m , Width : 2.00"/51 mm to 4.33"/110 mm, Core : 1.0"/25.4 mm I.D. |
| RFID Features |
Supports tags compatible with: UHF EPC Gen 2 V2, ISO/IEC 18000-63 and RAIN RFID protocols, Integrated RFID system is user-upgradable in the field and available on both 4" and 6" models, Adaptive Encoding Technology automatically selects optimum encode se |
| Barcode Sets |
Linear Barcodes: Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC Case Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2- or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI |
| Interface |
USB 2.0, high-speed, RS-232 Serial, 10/100 Ethernet, Bluetooth 2.1, USB Host |
| Voltage |
Auto-detectable (PFC Compliant) 100-240VAC, 50-60Hz |
| Power Consumption |
Rated at 100 Watts |
| Control Panel |
Back-lit, multiline graphic LCD display with intuitive menu and easy-to-use keypad for quick operation |
| Environment |
Operating Temperature: Thermal transfer = 40ºF to 104ºF/5ºC to 40ºC, Direct thermal = 32ºF to 104ºF/0ºC to 40ºC;Operating Humidity: 20% to 85% non-condensing, Storage/Transportation Temperature: -40ºF to 140ºF/-40ºC to 60ºC,Storage Humidity: 5% to 85% non |
| Certification |
IEC 60950, EN 55022 Class B, EN 55024, EN 61000-3-2, EN 61000-3-3, cTUVus, CE Marking, FCC-B, ICES-003, VCCI, C-Tick, NOM, S-Mark (Arg), CCC, CU, BSMI, KCC, SABS, IN-Metro |
| Dimension |
(LxWxH) 19.50 x 13.25 x 12.75 Inch |
| Weight |
18.14 kg |
