| Product Type |
Industrial Printer |
| Print Method |
direct-thermal or thermal-transfer (optional) |
| Body Material |
metal frame with plastic (ZT220) media cover |
| Sensors |
Transmissive and reflctive sensors |
| Memory |
Standard: 128MB flsh (58MB user-available),128MB DRAM |
| Resolution |
8 dots per mm/203dpi , 12 dots per mm/300dpi (optional) |
| Print Speed |
152mm/6" per second |
| Print Width |
104mm/4.09", Minimum: 0.75"/19.4mm |
| Media Type |
Continuous, die-cut, notch, black-mark |
| Media Size |
203mm/8.0" O.D on a 76mm/3.0" I.D. core ; 152mm/6.0" O.D. on a 25mm/1.0" I.D. core |
| Media Thickness |
0.076mm/0.003" to 0.25mm/0.010" |
| Ribbon Features |
(Thermal-transfer option only); 300m ribbon capacity; Outside diameter : 81.3mm/3.2" on a 25mm/1.0" I.D. core (ZT230) ; Standard length : 300m/984' (ZT220) or 450m/1,476' (ZT230) ; Ratio : 2:1 media-roll-to-ribbon ratio for ZT220, 3:1 media-roll-to-ribbon |
| Barcode Sets |
Linear barcodes: Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC Case Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN with 2 or 5 digitextensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, |
| Network |
ZebraNet 10/100 Print Server — supports 10/100 Ethernet networks internally integrated option that enables the use of ZebraLink Web View and Alert features ; ZebraNet Printer Server — supports 802.11a/b/g/n networks via an internally integrate option |
| Interface |
USB 2.0 and RS-232 Serial ports |
| Voltage |
Universal auto-ranging (PFC-compliant) power supply 100-240VAC; |
| Control Panel |
Simple 3-button keypad with bi-colored status LEDs for quick printer status |
| Environment |
Operating temperature: 5ºC to 40ºC (thermal-transfer) and 0ºC to 40ºC (direct-thermal), Storage temperature: -40ºC to 60ºC , Operating humidity: 20% to 85% non-condensing, Storage humidity: 5% to 85% non-condensing |
| Advanced Features |
Bi-fold media door with large clear window, Side-loading supplies path for simplifid media and ribbon loading, Element Energy Equalizer™ (E3™) for superior print quality, Bi-colour LEDs for quick printer status, Energy Star-compliant |
| Certification |
IEC 60950, EN 55022 Class B, EN 55024, EN 61000-3-2, EN 61000-3-3 ; Markings: cTUVus, CE Marking, FCC-B, ICES-003, VCCI, C-Tick, NOM, S-MARK, CCC, GOST-R,KCC, BSMI, UkrSepro |
| Language Supported |
7 bitmapped, 1 smooth-scalable (CG Triumvirate™ Bold Condensed).Contains UFST® from Agfa Monotype ; Pre-loaded Unicode™-compliant scalable fonts for EMEA character sets ; International character sets supporting the following code page: IBM ® Code Page 850 |
| Dimension |
(WxHxD) 9.4 x 11 x 17 Inch |
| Weight |
7.8kg/17lb |
