| Brand |
Cisco |
| Product Type |
TelePresence |
| Version |
Server 7010 |
| License Type |
|
| Language Supported |
English as standard |
| Feature 01 |
Design features: Offers multivendor telepresence interoperability, Standards-based and compatible with major vendors’ video conferencing endpoints, Intelligently recognizes the type of system joining a conference. |
| Feature 02 |
Application features: Supports single and multi-screen Cisco TelePresence systems, Interworking with Polycom RPX and TPX telepresence systems, Interconnects telepresence, high-definition, and standard-definition endpoints. |
| Feature 03 |
Performance features: Cisco ActivePresence supports a full-screen immersive view of the primary speakers with a seamless overlay of others in the call; designed to maximize the large-scale immersive telepresence experience for every participant, High-definition transcoding for every participant, Cisco TelePresence Universal Port technology. |
| Feature 04 |
High-definition performance: Up to 1080p, 30 fps, and 720p, 60 fps, H.264, 6Mbps ActivePresence (including content), Comprehensive HD audio, Dual video H.239, BFCP or Auto Collaborate. |
| Feature 05 |
Universal transcoding and transrating: This server combines telepresence, HD, and SD within the same virtual meeting, The server offers automatic audio and video transcoding and transrating on all calls, Any bandwidth, any resolution, and any video or audio codec can be used on any video call within the same meeting. |
| Feature 06 |
Cisco TelePresence Server features: Panel-switched Cisco ActivePresence view or standard telepresence view for all single-screen endpoints, Supports single and multi-screen Cisco Telepresence systems, Ability to initiate calls from the Cisco TelePresence user interfaces, Integration with Experia. |
| Feature 07 |
Content Features: Automatic Content Handover, Widescreen (16:9) support, Dual video using H.239, BFCP or Auto Collaborate. |
| Feature 08 |
Built-in web server: Complete configuration, control, and monitoring of the system and conferences. |
| Feature 09 |
Physical dimensions (H x W x D): 3.43 x 17.25 x 19.1 in. (87 x 436 x 511 mm) (2RU), 19" rack mountable (kit supplied) or standalone. |
| Feature 10 |
Weight: 22 lb (15 kg) |
| Feature 11 |
Power: Power: 100-240 VAC, 50/60Hz, Maximum power consumption: 650W |
| Feature 12 |
Environmental data: Ambient operating temperature: 32 to 95°F (0 to 35° C), Relative humidity: Below 95% (noncondensing) |
| Feature 13 |
Approvals and compliance: Compliance model number TR1A, European safety: EN 60950-1:2001, USA/Canada safety: UL 60950-1 CB, CE |
| Feature 14 |
Video standards: H.261, H.263, H.263+, H.263++, H.264; Video resolution: From QCIF up to 1080p (1920 x 1080) including interlaced iCIF and iSIF, Aspect ratios: 4:3 and 16:9; Frame rates: Up to 60 frames per second |
| Feature 15 |
Audio standards: G.711, G.722, G.722.1, G.723.1, G.728, G.729, MPEG-4 AAC-LC, MPEG-4 AAC-LD, Polycom Siren14/G.722.1 Annex C, Audio features: Wideband audio mixing, Ability to adjust endpoint audio gain through web interface |
| Feature 16 |
Protocols: H.323, Session Initiation Protocol (SIP), Telepresence Interoperability Protocol Version 7 (TIPv7), H.235 (AES), H.239 (dual video), FTP, Real-Time Transport Protocol (RTP), Real Time Streaming Protocol (RTSP), HTTP, Secure HTTP (HTTPS), Dynamic Host Configuration Protocol (DHCP) |
| Feature 17 |
Security features: Secure non-PC hardware and operating system, AES encryption, 128-bit key, H.235. |
| Feature 18 |
System management: XML management application programming interface (API), Management through embedded web server, RS-232 for local control and diagnostics, Configurable event logs and full H.323 and SIP decoding. |
| Feature 19 |
Network resilience: Cisco TelePresence PacketSafe technology provides intelligent down speeding, packet pacing, and packet-loss concealment to ensure optimum video and audio quality Dynamic jitter buffering. |
| Feature 20 |
Interfaces: RJ-45 Ethernet, 10/100/1000-Mbps full and half duplex, manual or auto sensing, RJ-45 serial port. |
