Up to 60 Mbps incoming bandwidth, and 60 Mbps outgoing bandwidth
Up to 8-ch network camera inputs
| Product Type | NVR |
| Resolution | 4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF |
| Recording / Playback Mode | Record Mode : Stream Type: Video, Video & Audio H.265+/H.265/ H.264+/H.264 |
| Connectivity | SATA : 1 SATA interface ; Capacity : Up to 6TB capacity for each disk ; Alarm In/Out : N/A ; USB Interface : Rear panel: 2 × USB 2.0 |
| Network Interface | 1, RJ-45 10/100Mbps self-adaptive Ethernet interface |
| Network Protocols | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP,UPnP™ |
| Input | IP Video Input : 8-ch Up to 4 MP resolution |
| Output | HDMI Output : 1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz ; VGA Output : 1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz ; Video Output Mode : HDMI/VGA simultaneous output |
| Power | 12 VDC, 1.5 A |
| Power Consumption | ≤ 10 W |
| Environment | Working Temperature : -10 to +55º C (+14 to +131º F) ; Working Humidity : 10% to 90% |
Up to 8-ch network camera inputs
