High quality imaging with 4 MP resolution
Clear imaging against strong backlight due to 120 dB WDR technology
| Product Type | IP Bullet Camera |
| Connectivity | Ethernet Interface : 1 RJ45 10M/100M self-adaptive Ethernet port ; On-Board Storage : Built-in memory card slot, support microSD card, up to 256 GB ; Built-in Microphone-U: Yes ; Reset Key : Yes |
| Effective Pixels | 4MP |
| Resolution | 2688 × 1520 |
| Luminance | Min. IlluminationColor: 0.005 Lux @ (F1.6, AGC ON), 0 Lux with IR on |
| Audio | Audio Compression : -U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC ; Audio Bit Rate : -U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps(G.722.1)/16 Kbps(G.726)/16 Kbps-64 Kbps(AAC) ; Audio Sampling Rate : -U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Lens Features | Lens Type : Fixed focal lens, 2.8, 4, and 6 mm optional ; Lens Mount : M12 ; Aperture : F1.6 ; Iris Type : Fixed |
| Angle of View | Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Protocol | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, WebSocket, WebSockets |
| Environment | Storage Conditions : -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) ; Startup and Operating Conditions : -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Power | 12 VDC ± 25%, 0.5 A, max. 6 W, Ø5.5 mm coaxial power plug, reverse polarity |
| Focal Length | 2.8 mm, horizontal FOV 103°, vertical FOV 55°, diagonal FOV 122° 4 mm, horizontal FOV 84°, vertical FOV 45°, diagonal FOV 100° 6 mm, horizontal FOV 52°, vertical FOV 28°, diagonal FOV 61° |
| Language Supported | 33 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| Shutter | Shutter Time : 1/3 s to 1/100,000 s |
Clear imaging against strong backlight due to 120 dB WDR technology
