| Model Size |
64" |
| Functions |
Print |
| Technology |
Advanced Look-Up Table (LUT) Technology |
| Speed |
720 x 1440 dpi, 44-pass (White and Silver); 11 SFPH, 720 x 1440 dpi, 36-pass (White); 32 SFPH,720 x 720 dpi, 2-pass; 550 SFPH,720 x 720 dpi, 8-pass; 140 SFPH,720 x 720 dpi, 6-pass; 190 SFPH |
| Nozzle Configuration |
Color and Monochrome 720 nozzles per Color |
| Memory |
Main : 512MB, Network : 128MB |
| Resolution |
1440 x 1440 dpi; 1440 x 720 dpi; |
| Ink Type |
Epson UltraChrome@GSX |
| Cartridges Number |
10-cartridge (C, M, Y, K, Lc, Lm, Lk, O + Optional W and MS |
| Supported Consumables |
Black T715100,Cyan T715200, Magenta T715300, Yellow T715400, Light Cyan T715500, Additional Print Drying System : C12C890751, Heavy Roll Media System : C12C890761, Waste Ink Bottle : C13T724000, Maintenance Kit : C13T724100, Ink Cleaner : C13T699300 |
| Ink Supply System |
Ink Capacity : 700ml (C,M,Y,K), 600ml (White), 350ml (Metalic Silver) |
| Media Size |
Width : Max- 1615.6mm (64") |
| Media Weight |
Width : 300-1625.6mm (64") |
| Media Thickness |
from 45 gsm up to 1.0 mm thick |
| Color Depth |
Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Light Black, Orange, (Configurable) White, Metalic Silver |
| Control Panel |
2.5" Colour LCD |
| Interface |
Standard: USB 2.0 Hi-Speed; Ethernet: 100Base-TX/1000Base-T |
| Voltage |
Rated Voltage : AC 100-240V |
| Rated Frequency |
50~60Hz |
| Power Consumption |
Operating : Approx. 800W, Standby : Approx.580W, Sleep : Approx. 12W, Power Off : Less than 0.6W |
| Rated Current |
20A at AC 110-120 V or 10A at AC 200-240 V |
| OS Compatibility |
Macintosh® 10.5+, Windows 7, Vista or XP (32-bit or 64-bit) |
| Environment |
Operating: 59° to 86°F (15° to 30°C) Storage: -4° to 104°F (-20° to 40°C) |
| Included Accessories |
Power Cord 1.9m, Ethernet Cat-5e cable 1.8m, Starter Ink Set (Cyan, Magenta, Yellow, Black, Light, Cyan, Light Magenta, Light Magenta, Light Black, Orange, White, Metalic Server) User Manul Set, 10x Cleaning Cartridges |
| Advanced Features |
Driver and utilities (CD),Individual Ink Cartridges,Installation/safety manual,Main unit,Power cable,Setup guide,User manual,Warranty Documents |
| Dimension |
1,608(W) x 917(D) x 1,128(H) mm |
| Weight |
90 kg (without ink) |
