| Functions |
Print |
| Technology |
Impact dot matrix |
| Number of Pins |
24 pins |
| Speed |
Print Speed: 10 cpi, 12 cpi, 15 cpi, 17 cpi (condensed) 20 cpi (condensed), HIGH SPEED DRAFT:480 cps, 576 cps, DRAFT : 360 cps, 432 cps, 540 cps, 308 cps, 360 cps, LETTER QUALIT0Y: 120 cps, 144 cps, 180 cps, 205 cps, 240 cps |
| MTBF |
20000 Power on hours (POH) (25% Duty) |
| Print Head Life |
400 million strokes/wire |
| Character Sets |
14 international character sets and one legal character sets, 1 italic and 12 graphical character tables: Italic table, PC 437 (US Standard Europe), PC850 (Multilingual), PC860 (Portuguese), PC861 (Icelandic), PC863 (Canadian-French), PC865 (Nordic), BRASCII, Abicomp, Roman 8, ISO Latin 1, PC 858, ISO 8859-15 |
| Supported Bitmap Fonts |
EPSON DRAFT / EPSON COURIER 10 cpi, 12 cpi, 15 cpi, EPSON ROMAN / EPSON SANS SERIF 10 cpi, 12 cpi, 15 cpi, Proportional, EPSON PRESTIGE 10 cpi, 12 cpi, EPSON SCRIPT / OCR-B / ORATOR / ORATOR-S / 10 cpi, EPSON SCRIPT C Proportional |
| Supported Scalable Fonts |
EPSON ROMAN/SANS SERIF / ROMAN T / 10.5 pt., 8 pt. - 32 pt. (every 2 pt.), SANS SERIF H |
| Barcode Sets |
EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, POSTNET, Coda bar (NW-7), Industrial 2 of 5, Matrix 2 of 5 |
| Media Cut Sheet |
Single: Entry: Front: WIDTH 100 - 420 mm (3.9 - 16.5”), LENGTH 148 - 420 mm (5.8 - 16.5“), THICKNESS 0.065 - 0.14 mm (0.0025 - 0.0055”), Entry: Rear: Width-100 - 420 mm (3.9 - 16.5“), Length: 100 - 420 mm (3.9 - 16.5”), Thickness: 0.065 - 0.14 mm (0.0025 - 0.0055“) |
| Envelopes Media |
Entry: Rear, Envelopes (No.6)-WIDTH x LENGTH 165 mm (6.5”) x 92 mm (3.6”), TOTAL THICKNESS 0.16 - 0.52 mm (0.0063 - 0.020”), Envelop (No. 10) WidthxLength: 241 mm (9.5”) x 105 mm (4.1”), Total Thickness: 0.16 - 0.52 mm (0.0063 - 0.020”) |
| Continuous Paper |
Entry: Front, Rear, Bottom, WIDTH x LENGTH x TOTAL THICKNESS 101.6 - 406.4 mm (4 - 16”) x 101.6 - 558.8 mm (4 - 22”) x 0.065 - 0.46 mm (0.0025 - 0.018“) |
| Roll Media Handling |
Entry: Rear: WIDTH x DIAMETER x THICKNESS 216 mm (8.5”) x 127 mm (5“) x 0.07 - 0.09 mm (0.0028 - 0.0035”) |
| Multipart Copy |
1 original + 5 copies |
| Print Direction |
Bi-directional with logic seeking, Manual Insertion (Front or rear in, top out), Push Tractor (Front or rear in, top out), Pull Tractor (Front or rear or bottom in, top out) |
| Emulation |
ESC/P2 and IBM PPDS emulation |
| Memory |
Input Data Buffer: 128 KB |
| Supported Consumables |
Fabric Ribbon Cartridge, Color: Black, Ribbon Life: Approx. 8 million characters |
| Interface |
Bi-directional parallel interface (IEEE-1284 nibble mode supported), USB 2.0 (Full speed), Type B I/F Level 2 (Optional) |
| Control Panel |
6 switches and 10 LEDs are located on teh panel, Noise: 54dB |
| Voltage |
AC 120V, AC 220 V to 240 V |
| Rated Frequency |
50 to 60 Hz |
| Power Consumption |
Approx 46W (ISO/IEC 10561 Letter pattern), Approx: .W in sleep mode, 0 W in powered off mode, Energy Star Compliant |
| OS Compatibility |
Microsoft®, Windows®200/XP/Vista/7 |
| Environment |
Temperature: 5 to 35º C (Operating) 15 to 25ºC (Opeating), 10 to 80% RH (Opeating), 30 to 60% RH (Operating) |
| Dimension |
WxDxH: 639mmx402m,mx256mm |
| Weight |
13.0 Kgs |
