| Country of Origin |
USA |
| WAN/LAN Ports |
12 dual-purpose (10/100/1000 and SFP) ports |
| Slots |
Slots for field-replaceable power supplies and fan modules |
| Bandwidth |
Forwarding: Cisco ME 3400EG-12CS AC or DC: 32 Gbps |
| Forwarding Rate |
Cisco ME 3400EG-12CS, AC or DC: 26 mpps |
| MAC Address |
Configurable up to 8000 MAC addresses |
| Memory |
128 -MB DRAM and 32 MB flash memory |
| MTBF |
Cisco ME 3400EG-12CS with one AC or one DC: 196,391 hours, Cisco Office Product Specification: 48 dBA (sound pressure), 4.8 bels (sound power), EN 300 753 |
| Power |
AC Input Voltage : Cisco ME 340X-PWR-AC: 100 to 240 VAC (+/- 10% autoranging), 1.5 to 1\0.7A, Frequency: 50 to 60 Hz, DC Input Voltages: Cisco ME340X-PWR-DC: 18 to 72 VDC, 8 to 4A (18 to 36V), 4 to 2A (36 to 72V), Power Consumption: Cisco ME 3400EG-12CS-M |
| Standards |
IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports, IEEE 802.1D Spanning Tree Protocol, IEEE 802.1p CoS classification, IEEE 802.1Q VLAN, IEEE 802.3 10BASE |
| Protocol |
Layer 2 protocols: Cisco Discovery Protocol, Link Layer Discovery, Protocol (LLDP), Link Aggregation Control Protocol (LACP), Port Aggregation Protocol (PAgP), and Spanning Tree Protocol. |
| Cabling Type |
1000BASE-T SFP-based ports: RJ-45 connectors, 4-pair Category 5 UTP cabling, 10/100/1000BASE-T, operation in host systems with SGMII interface |
| Form Factor |
Compact |
| Control Panel |
Per-port status LEDs: Link integrity, port disabled, and activity indications, System-status LED |
| Safety |
UL 60950-1, First Edition, CUL to CAN/CSA 22.2 No.60950-1, First Edition, TUV/GS to EN 60950-1, CB report/certificate to IEC 60950 with all country deviations, NOM to NOM-019-SCFI (through distributors), CE Marking |
| Environment |
Operating environment: Temperature: 0 to 65ºC, Altitude: Up to 13,000 ft (4000m), Relative humidity: 10 to 95% noncondensing, Storage environment: Temperature: –40 to 70ºC, Altitude: 15,000 ft (4570 m) |
| Advanced Features |
Project management, Site survey, configuration, and deployment, Installation, text, and cutover, Training, Major moves, adds, and changes, Design review and product staging |
| Weight |
8.5 lb (3.9 kg) |
| Dimension |
1.75 x 17.5 x 12.0 in. (4.45 x 44.5 x 30.5 cm) |
