Cisco delivers a comprehensive portfolio of switching solutions for Enterprise Networks, data centers, and smaller businesses and the public sector.
The Cisco® Catalyst® 3750-X Series Switches are an enterprise-class lines of stackable and standalone switches, respectively. These switches provide high availability, scalability, security, energy efficiency, and ease of operation with innovative features such as Cisco StackPower (available only on the Catalyst 3750-X), IEEE 802.3at Power over Ethernet Plus (PoE+) configurations, optional network modules, redundant power supplies, and Media Access Control Security (MACsec) features.
Country of Origin | USA |
Model | WS-C3750X-24T-L |
WAN/LAN Ports | 10GbE Network Module: SFT+Ports2+1, GbE SFT Ports: 4 |
Ethernet/RJ-45 Ports | 1000BASE-T ports, 1000BASE-T SFP-based ports |
Support PoE | 24 Ports |
Forwarding Rate | 65.5 mpps |
Switching Capacity | 160 Gbps |
VLAN | 1005, IDs: 4K |
Memory | DRAM: 256 MB (512 MB for 3750X-12S and 3750X-24S), Flash: 64 MB (128 MB for 3750X-12S and 3750X-24S) |
Jumbo Frames | 9216 Byte |
MTBF | 189704, Calculated MTBF must be greater than 300,000 using Telcordia SR-332, Method 1, Case 3. Demonstrated MTBF is 500,000 hr (with 90% confidence level), Noise With AC Power Supply (with 16PoE+ ports loaded): LpA: 43 dbA Typical, 46 dbA Maximum, LwA: 5. |
Power | Voltage: 100 and 240VAC, Power Consumption: 93.6, Weighted Average: 93.0, Defaulth AC power: 350 Watt, Stack Power: Available with upgrade to IP Base, Available PoE with DC Power Supply : 24 Port PoE Switch- 440W DC PS, Total Available PoE Budget : 220W, |
Standards | IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3ad, IEEE 802.1ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports, IEEE 802.1D Spanning Tree Protocol, IEEE 802.1p CoS Prioritization, IEEE |
Routing | 468 Ports |
Cabling Type | Cat-5E UTP cabling |
Control Panel | “AC OK”: Input power to the power supply is OK, “PS OK”: Output power from the power supply is OK |
Safety | UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, CCC |
Environment | With AC Power Supply: -5ºC to +45ºC, up to 5,000 feet (1500 m), -5ºC to +40ºC, up to 10,000 feet (3000 m), Relative Humidity: 5% to 95%, noncondensing, Storage Environment: Temperature: -40 C' to 70 C', Altitude: 15,000 ft, Not more than following in one |
Certification | UL60950-1, C-UL to CAN/CSA 22.2 No.60950-1, TUV/GS to EN 60950-1, CB to IEC 60950-1 with all country deviations, AS/NZS 60950-1, CE Marking, NOM (through partners and distributors), GOST (Russia Safety Mark) |
Weight | 7.1 Kgs |
Dimension | 1.75 x 17.5 x 18.0 |
The Cisco® Catalyst® 3750-X Series Switches are an enterprise-class lines of stackable and standalone switches, respectively. These switches provide high availability, scalability, security, energy efficiency, and ease of operation with innovative features such as Cisco StackPower (available only on the Catalyst 3750-X), IEEE 802.3at Power over Ethernet Plus (PoE+) configurations, optional network modules, redundant power supplies, and Media Access Control Security (MACsec) features.
