| Product Type |
VoIP phone |
| Mounting |
You can install the phone on a wall using an optional wall-mount kit (available separately) |
| Display |
5" / 12.7 cm |
| Resolution |
384 x 106 pixel, 24-bit color |
| LED Indicator |
The phone supports backlit indicators for the audio path keys (Handset, Headset, and Speakerphone), select key, line keys, and message waiting |
| Buttons |
Programmable Soft Keys : 4 , Number of Line Keys : 5; The phone has the following keys: Line keys , Soft keys, Back and release keys, Four-way navigation and select keys, Hold/Resume, Transfer, and Conference keys, Messaging, Application, and Directory keys, Standard keypad, Volume-control toggle key, Speakerphone, headset, and mute keys |
| Audio Features |
Wideband Audio ; The phone has a 3.5-mm stereo line in/out jack (for optional external headset, speakers, or headphones) |
| Volume Control |
toggle key |
| Audio Codec |
G.711a/μ, G.722, G.729a, iLBC |
| Speaker Type |
Full Duplex Speakerphone |
| IP Features |
The phone is an interoperable IEEE 802.3af PoE (Class 1 device); 48 VDC is required; it can be supplied locally at the desktop using an optional AC-to-DC power supply (CP-PWR-CUBE-3=). Use of the power supply also requires the use of one of the corresponding AC country cords. |
| Network Interface |
The phone has a 10/100BASE-T or a 10/100/1000BASE-T |
| Connectivity |
Bluetooth : Bluetooth 4.1 LE, Enhanced Data Rate (EDR) Class 1 technology (up to 66-ft [20m] range) is supported ; Hands-Free Profile (HFP) is supported for untethered headset connections and voice communications , Phone Book Access Profile (PBAP) is supported for phone book object exchange between devices ; Headset Jack : The analog headset jack is a standard wideband-capable RJ-9 audio port ; I/O Connector : You can use an auxiliary port to support electronic hookswitch control with a third-party headset connected to it |
| Environment |
Operational temperature : 32 to 104°F (0 to 40°C) ;Nonoperational temperature shock : 14 to 140°F (-10 to 60°C) ; Humidity : Operating 10% to 90%, non-condensing, Non-operating 10% to 95%, non-condensing |
| Feature 01 |
+ Dialing (E.164), Abbreviated dial, Adjustable ringing and volume levels , Adjustable display contrast , Agent greeting, Auto-answer, Auto-detection of headset (Not available on the IP Phone 7811), Busy Lamp Field (BLF) (Not available on the IP Phone 7811), Call back, Call forward , Call history, Call park , Call Pickup, Call timer , Call waiting , Caller ID , cBarge, Corporate directory, Conference, Cross Cluster Extension Mobility (EMCC) , Dial from the list , Direct transfer, Do not disturb , Extension Mobility (EM), Forced access codes and client matter codes, Group call pickup , Hold/resume, Immediate divert , Intercom (Not available on the IP Phone 7811) , Join (Not available on the IP Phone 7811) , Message-waiting indicator, Meet me conference , Mobility, Music on hold , Mute , Network profiles (automatic), On- and off-network distinctive ringing , Personal directory , Privacy, Private Line Automated Ringdown (PLAR), Redial , Ring tone per line appearance Shared line , Silent monitoring and recording , Speed dial, Time and date display, Transfer, Voicemail, whisper coaching |
| Feature 02 |
Language Support : Arabic (Arabic Area), Bulgarian (Bulgaria), Catalan (Spain), Chinese (China), Chinese (Hong Kong), Chinese (Taiwan), Croatian (Croatia), Czech (Czech Republic), Danish (Denmark), Dutch (Netherlands), English (United Kingdom), Estonian (Estonia), French (France), French (Canada), Finnish (Finland), German (Germany), Greek (Greece), Hebrew (Israel), Hungarian (Hungary), Italian (Italy), Japanese (Japan), Latvian (Latvia), Lithuanian (Lithuania), Korean (Korea Republic), Norwegian (Norway), Polish (Poland), Portuguese (Portugal), Portuguese (Brazil), Romanian (Romania), Russian (Russian Federation), Spanish (Columbia), Spanish (Spain), Slovak (Slovakia), Swedish (Sweden), Serbian (Republic of Serbia), Serbian (Republic of Montenegro), Slovenian (Slovenia), Thai (Thailand), Turkish (Turkey |
| Feature 03 |
(Call-Control Support):- Cisco Unified Communications Manager : 8.5.1 (Non-secured mode Only) , 8.6.2 , 9.1.2 , 10.0 and later ; Cisco Unified Communications Manager Express (Unified CME) :- 8.6.2 , 9.1.2 , 10.0 and later ; Cisco Hosted Collaboration Solution (HCS) : 8.6.2 and later (using supported UCM versions above) |
| Feature 04 |
Video : 720p HD, H.264/AVC ; Stand : The display is easy-to-view and the buttons and keys are easy-to-use. The two-position foot stand supports viewing angles of 35 and 50 degrees; you can remove the foot stand for wall mounting, with mounting holes located on the base of the phone |
| Power Consumption |
IEEE Power over Ethernet class 4. The phone is compatible with IEEE 802.3af, 802.3at and UPOE switch blades and supports both Cisco Discovery Protocol and Link Layer Discovery Protocol - Power over Ethernet (LLDP-PoE ; Cisco IP Phone Power Cube 4 : This optional power cube is used as an AC-to-DC (48V) power supply for non-PoE deployments. Use of the power cube 4 also requires the use of one of the corresponding AC country cords ; Cisco Power Injector : 8865 is compatible with Cisco Aironet Power Injector AIR_PWRINJ6=, which can provide an alternative POE solution when the LAN switch doesn’t support POE and the customer mandates one RJ45 cable to the table strategy. |
| Certification |
• Regulatory compliance : CE Markings per directives 2004/108/EC and 2006/95/EC ; Safety : UL 60950 Second Edition, CAN/CSA-C22.2 No. 60950 Second Edition, EN 60950 Second Edition (including A11 and A12), IEC 60950 Second Edition (including A11 and A12), AS/NZS 60950, GB4943 ; EMC - Emissions : 47CFR Part 15 (CFR 47) Class B, AS/NZS CISPR22 Class B, CISPR22: 2005 w/Amendment 1: 2005 Class B, EN55022: 2006 w/Amendment 1: 2007 Class B, ICES003 Class B, VCCI Class B, EN61000-3-2,EN61000-3-3, KN22 Class B ; EMC - Immunity : EN55024, CISPR24, EN60601-1-2 , KN24 , Armadillo Light: Telecom : FCC Part 68 HAC, CS-03-HAC, AS/ACIF S004, AS/ACIF S040, NZ PTC 220, Industry standards: TIA 810 and TIA 920, Industry standards: IEEE 802.3 Ethernet and IEEE 802.3af and 802.3at, Korea (RRA Public Notification 2010-36, Nov. 1, 2010), Korea (RRA Announce 2011-2, Feb. 28, 2011) ; Radio : FCC Part 2.1093 (BT RF Exposure TR), RSS-102 (BT RF Exposure TR), RSS-210, EN 300.328, EN50385 (BT RF Exposure TR), EN 301-489-1, EN 301-489-17, NCC LP0002, Korea (RRL No. 2006-128, RRL No. 2006-129), Japan Bluetooth GFSK/EDR |
| Dimension |
(HxWxD) 9.02 x 10.13 x 1.57 in. |
| Weight |
1.17 kg |
