| Copier Type |
Colour Laser Multifunctional |
| Functions |
Print, Copy, Scan, Send, Store and Optional Fax |
| Speed |
Print: 35 ppm (A4), 18 ppm (A3), Copy: 35 ppm (A4), 18 ppm (A3), Scan: 80-160 ipm |
| Resolution |
Print: 600 dpi x 600 dpi (Default), 1,200 dpi x 1,200 dpi), Copy: Reading: 600 dpi x 600 dpi, Printing: Up to 1,200 dpi x 1,200 dpi, Scan: 100-600dpi, Fax: 400-100 dpi |
| Processor |
Canon Dual Custom Processor (Shared) |
| Memory |
Standard: 4.0GB RAM, Fax Memory: Up to 30,000 pages |
| Hard Disk Drive |
Standard: 250GB, Maximum: 1TB, Mirroring Hard Disk Drive : Optional 250GB, 1TB |
| Warm-Up Time |
30 Seconds or Less |
| Recovery from Sleep Mode |
10 Seconds or Less |
| First Page Out Time |
Approx. 4.9 seconds or less (BW), Approx. 7.4 seconds or less (CL) |
| Duplex Print |
Automatic (Standard) |
| Feeding Capacity |
Standard: 1,200 Sheets, Maximum: 6,350 Sheets, Paper Source: Two 550-sheet Paper Cassettes 100-sheet Multi-purpose tray, Maximum: 6,350 Sheets |
| Media Type |
Supported Media Types: Cassette 1: Thin paper, Plain paper, Thick paper, Colour paper, Recycled paper, Pre-punched paper, Transparency*, Bond paper, Envelope, Letterhead, Cassette 2: Thin paper, Plain paper, Thick paper, Colour paper, Recycled paper, Pre- |
| Media Size |
Cassette1: Standard size: A4, B5, A5, A5R, Custom Size: 98.0 mm x 148 mm to 297 mm x 215.9 mm, Cassette 2: Standard size: A3, B4, A4, A4R, B5, B5R, A5 Foolscap, India Legal, F4A , Custom size: 98.0 mm x 182 mm to 304.8 mm x 457.2 mm , CASSETTE FEEDING UNI |
| Media Weight |
Cassettes : 52 to 256 gsm, Multi-purpose tray : 52 to 300 gsm, Duplex : 52 to 220 gsm |
| Multiple Copies / Prints |
Up to 999 copies |
| Zoom Rate |
Magnifiation: 25% - 400% (1% Increments), Preset Reductions: 25%, 50%, 61%, 70%, 81%, 86%, Preset Enlargements: 115%, 122%, 141%, 200%, 400% |
| Scanner Type |
Type: Single-pass Duplexing Automatic Document Feeder, Supported Media Size: A3, A4, A4R, A5, A5R, B4, B5, B5R, B6R, Weight of Media Supported: Single-sided scanning: 38* to 157 gsm (BW), 64 to 157 gsm (CL), Double-sided scanning: 50 to 157 gsm (BW), 64 t |
| Output File Format |
Standard: JPEG, TIFF, PDF/XPS (Compact), PDF(PDF/A-1b, Optimize for Web, Apply Policy), Optional: PDF (Trace&Smooth, Encrypted), PDF/XPS (Digital Signature, Searchable), Office Open XML (Powerpoint, Word) |
| Fax Features |
Standard: Optional on all models, Max. Connection Line: 4 |
| Modem Speed |
Super G3: 33.6 kbps, G3: 14.4 kbps |
| Speed Dial |
Max. 200, Group Dials: Max. 199 dials |
| Address Book Capacity |
LDAP (2,000)/Local (1,600)/One-touch (200) |
| Compression Method |
MH, MR, MMR, JBIG |
| Network Interface |
Standard : 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n) Optional: NFC, Bluetooth |
| Control Panel |
10.1 inch TFT LCD WSVGA Colour Touchpanel |
| Compatible Accessories |
NPG-71 TONER BK/C/M/Y, NPG-71L TONER BK/C/M/Y , STAMP INK CARTRIDGE-C1, STAPLE-P1, STAPLE CARTRIDGE-Y1 |
| OS Compatibility |
UFRII: Server 2003/Server 2003 R2/Windows Vista/Server 2008/Windows 7/Server 2008 R2/Windows 8/Server 2012/Windows 8.1/Server 2012 R2/Windows 10, MAC OS X(10.6.8 or later) |
| Security |
Network: Standard: IP/Mac Address Filtering, IPSEC, TLS Encrypted Communication, SNMP V3.0, IEEE 802.1X, IPv6, SMTP Authentication, POP Authentication before SMTP Document, Standard: Secure Print, Force Hold Print, Optional: Encrypted PDF, Encrypted Secur |
| Power |
220-240V (±10 %) , 50/60Hz (±2 Hz) , 6Amp |
| Environment |
Temperature: 10 to 30 ºC (50 to 86 ºF), Humidity: 20 to 80 % RH (no condensation) |
| Power Consumption |
Power Consumption: Maximum: 1.8 kW, Standby: Approx. 67.9 W, Reference Value: Sleep mode: Approx. 0.8 W |
| Interface |
Standard: USB 2.0 x2 (Host), USB 3.0 x1 (Host), USB 2.0 x1 (Device), Optional: Serial Interface,Copy Control Interface |
| Dimension |
620 mm x 742 mm x 950 mm |
| Weight |
Approx. 143kg, Including the toner bottle |
