| Copier Type |
Colour Laser Multifunctional |
| Functions |
Print, Copy, Scan, Send, Store and Optional Fax |
| Speed |
20ppm in A4 (B&W / Colour) |
| Resolution |
Print: Up to 1,200 dpi x 1,200 dpi, Copy: Reading : 600 dpi x 600 dpi, Printing : Up to 2400dpi equivalent × 600dpi, Scan: 600 x 600 dpi, Fax: 400 x 400 dpi, 200 x 400 dpi |
| Processor |
Canon Dual Custom Processor (Shared) |
| Memory |
Standard : 3.0GB RAM, Fax: Up to 30,000 pages |
| Hard Disk Drive |
Standard: 250GB, Maximum: 1TB |
| Warm-Up Time |
34 Seconds or Less |
| Recovery from Sleep Mode |
10 Seconds or Less |
| First Page Out Time |
Approx. B-W/C: 5.9/8.2 seconds or less |
| Duplex Print |
Automatic (Standard) |
| Feeding Capacity |
Standard : 1,200 Sheets, Maximum : 2,300 Sheets, Output Capacity: Standard:250 Sheets, Maximum:3,450 Sheets (with BOOKLET FINISHER-AA1 or COPY TRAY-J2) |
| Media Type |
Cassettes (1/2) : Thin paper, Plain paper, Thick paper, Colour paper, Recycled paper, Pre-punched paper, Transparency*, Bond paper, Envelope, Multi-Purpose Tray: Thin paper, Plain paper, Thick paper, Colour paper, Recycled paper, Pre-punched paper, Transp |
| Media Size |
Cassette 1 : Standard size : A4, B5, A5R, nvelopes : No.10 (COM10), ISO-C5, DL, Custom Size : 139.7 x 182 mm up to 297 x 215.9 mm, Cassette 2: Standard size : A3, B4, A4, A4R, B5, A5R, Foolscap, India Legal, F4A, Envelopes, (No. 10(COM 10), Monarch, ISO-C |
| Media Weight |
CASSETTES : 52 to 220 gsm, MULTI-PURPOSE TRAY : 52 to 300 gsm, DUPLEX : 52 to 220 gsm |
| Multiple Copies / Prints |
Up to 999 copies |
| Zoom Rate |
Magnifiation: 25% - 400% (1% Increments), Preset Reductions: 25%, 50%, 61%, 70%, 81%, 86%, Preset Enlargements: 115%, 122%, 141%, 200%, 400% |
| Scanner Type |
Type: Single-pass Duplexing Automatic Document Feeder or Duplexing Automatic Document Feeder Document Feeder Paper Capacity, SINGLE PASS (SP) DADF-A1: 150 Sheets (80 gsm) DADF-AV1: 100 Sheets (80 gsm), Document Feeder Supported, Media Sizes: SP DADF-A1: A |
| Fax Features |
Optional on all models, Max number of connection: 2 |
| Modem Speed |
Super G3 : 33.6 kbps, G3: 14.4 kbps |
| Speed Dial |
Max. 200, Group Dials: Max. 199 dials |
| Address Book Capacity |
LDAP (2,000)/Local (1,600)/Speed dial (200) |
| Compression Method |
MH, MR, MMR, JBIG |
| Network Interface |
Interface Connection: Network Standard : 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n) Optional : NFC, Bluetooth |
| Control Panel |
Standard : 10.1 inch TFT LCD WSVGA Colour Touch Panel |
| Compatible Accessories |
Toner Cartridge/s NPG-54 TONER BK, Toner (Estimated Yield @6% Coverage) 56,000 pages |
| OS Compatibility |
Windows Vista/Server 2008/Windows 7/Server 2008 R2/ Windows 8/Server 2012/Windows 8.1/Server 2012 R2/ Windows 10/Server 2016, MAC OS X (10.7 or later) |
| Security |
Network : Standard : IP/Mac Address Filtering, IPSEC, TLS Encrypted Communication, SNMP V3.0, IEEE 802.1X, IPv6, SMTP Authentication, POP Authentication before SMTP, Document: Standard : Secure Print, Force Hold Print, Optional : Encrypted PDF, Encrypted |
| Power |
220-240V(±10 %) , 50/60Hz (±2 Hz), 4.0A |
| Environment |
Temperature: 10 to 30 ºC, Humidity: 20 to 80 % RH (no condensation) |
| Power Consumption |
Maximum: 1.5 kW, Standby: Approx. 41.2 W*, Sleep mode: Approx. 0.8 W ** |
| Dimension |
With SINGLE PASS DADF-A1: 565 x 742 x 900 mm, With DADF-AV1: 565 x 736 x 880 mm |
| Weight |
Approx. 68kg, Approx. 81.5kg (with SINGLE PASS DADF-A1), Approx. 76.2kg (with DADF-AV1) |
