| Model Size |
24” |
| Functions |
Print |
| Technology |
5 Colour 24 Inch |
| Speed |
CAD Drawing - Plain Paper (A1 size) : 0:24 (Fast Economy Mode), 0:27 (Fast), 0:42 (Standard) ; CAD Drawing - Heavyweight Coated Paper HG (A1 size) : 0:29 (Fast Economy Mode), 0:40 (Fast), 1:17 (Standard) ; Poster - Plain Paper (A1 size) : 0:25 (Fast Economy Mode) , 0:25 (Fast), 0:44 (Standard) ; Poster - Heavyweight Coated : 0:55 (Fast) ; Paper HG (A1 size) : 1:22 (Standard) |
| Nozzle Configuration |
1200dpi (2 lines) |
| Memory |
Standard memory : 2GB |
| Resolution |
2400 x 1200dpi |
| Ink Type |
Pigment inks / 5 colour - (MBK, BK,C,M, Y) |
| Ink Supply System |
Ink Droplet Size : Minimum 5 Picoliter per colour ; Ink Capacity : Sales Ink: 130ml/300ml (MBK, BK,C,M, Y) ; Bundled Starter Ink: 130ml (MBK)/ 90ml (BK,C,M, Y) |
| Media Size |
Minimum Printable Length : Roll Paper: 203.2mm , Cut Sheet: 279.4mm ; Maximum Printable Length :Roll Paper: 18m (Varies according to the OS and application) , Cut Sheet: 1.6m |
| Roll Media Handling |
Media Feed Method : Roll Paper: One Roll, Upper-loading, Front Output, Cut Sheet: Upper-loading, Front Output (Manual feed using media locking lever) ; Media Output (SD-23) : Standard Position: 1 Sheet, Folding Position: 20 sheets on A1 portrait, Flat Position: 20 sheets on A2 landscape ; Media Width : Roll Paper/Cut Sheet: 203.2 - 610mm |
| Media Thickness |
Roll Paper/Cut Sheet: 0.07 - 0.8mm |
| Line Accuracy |
±0.1% or less |
| Network |
Gigabit Ethernet: IEEE 802.3 10base-T, IEEE 802.3u 100base-TX / Auto-Negotiation, IEEE 802.3ab 1000base-T/ Auto-Negotiation, IEEE 802.3x Full Duplex ; Wireless LAN: IEEE802.11n/ IEEE802.11g/ IEEE802.11b |
| Interface |
USB B Port: Built in (Hi-Speed USB ), Full Speed (12 Mbit/sec), High Speed (480 Mbit/sec), Bulk transfer, Series B (4 pins) |
| Voltage |
AC 100-240V (50-60Hz) |
| Power Consumption |
Operation: 69W or less, Sleep Mode: 3.6W or less, Power Off: 0.3W or less |
| Environment |
Temperature: 15°C - 30°C, Humidity: 10% - 80% RH (no dew condensation) |
| Noise Level |
Operation: 44dB(A) (Plain paper, line drawing, standard mode), Standby : 35dB(A) or less, (Measured on ISO7779 standard),Operation : 6.0 Bels (Plain paper, line drawing, standard mode) |
| Language Supported |
SG Raster (Swift Graphic Raster), HP-GL/2, HP RTL, JPEG (Ver. JFIF 1.02) |
| Dimension |
Main Unit + Stand + Basket (SD-23) Basket Opened: 982 x 887 x 1060mm, Basket Closed: 982 x 757 x 1060mm |
| Shipping Dimension |
Printer (Main Unit with Pallet): 1152 x 913 x 705mm, 69kg ; Stand + Basket (SD-23): 1155 x 824 x 268mm, 18kg ; Printer (Main Unit with Stand SD-23 and Pallet): 1152 x 913 x 961mm, 87kg |
| Weight |
52 kg (including Roll Holder Set, excluding ink and print head) |
