Enables centralized management via the APC InfraStruXure Manager.
Provides early-warning fault analysis ensuring proactive component replacement. Periodic battery self-test ensures early detection of a battery that needs to be replaced. Warns when a battery is not available to provide backup power. Provides notification of changing utility power and UPS power conditions. Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
| Country of Origin | USA |
| Topology | Double Conversion Online |
| Capacity | Output Power : 3500 Watts / 5000 VA |
| Output Voltage | Nominal : 230V; Note : Configurable for 220 : 230 or 240 nominal output voltage |
| Frequency | Input: 50/60 Hz +/- 5 Hz (auto sensing); Output: 50/60 Hz +/- 3 Hz user adjustable +/- 0.1 |
| Input Connection | Hard Wire 3-wire |
| Output Connection | (8) IEC 320 C13; (2) IEC 320 C19; (4) IEC Jumpers |
| Efficiency | at Full Load : 92.0% |
| Recharge Time | Typical : 2.50 hour(s) |
| Interface | RJ-45 10/100 Base-T, RJ-45 Serial, Smart-Slot |
| Protection | Class : IP 20 |
| AC Power Surge Protection | Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
| Data Line Surge Protection | 555J Joules |
| Control Panel | LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : Overload and Bypass Indicators |
| Waveform Type | Sine wave |
| Crest Factor | 3 : 1 |
| Bypass | Internal Bypass (Automatic and Manual) |
| Environment | Opearating: 0 - 40 °C; Storage: -15 - 45 °C |
| Relative Humidity | 0 - 95% no% |
| Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| Noise Level | 55.00 dBA |
| Approvals | C-tick, CE, EN 50091-1, EN 50091-2, EN 55022 Class A, EN 60950, EN 61000-3-2,GOST, UL 1778, VDE |
| Dimension | WxHxD- 63.64 KGx 347.00 mm x 603.00 mm; Rack Height : 3U |
Provides early-warning fault analysis ensuring proactive component replacement. Periodic battery self-test ensures early detection of a battery that needs to be replaced. Warns when a battery is not available to provide backup power. Provides notification of changing utility power and UPS power conditions. Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
